HazMat



Charlotte Fire Department

Charlotte, North Carolina

Model DFC1164-R24

Specifications

Features:
  • Charlotte supplied Spartan LFD. Cab was completely gutted. New seats, windshield, inner door panels and headliner. Dash and engine cover painted with textured vinyl process. Exterior repaint.
  • Extended front bumper with new stainless steel bumper and (2) reel compartments.
  • Aluminum cabinets behind driver and officers seats with adjustable shelves
  • 36” wide floor to ceiling cabinet on center of rear wall with (3) individual access doors
  • Hackney 22-ft customized hazmat body.
  • Drop/pinch frame modification
  • 96” wide x 12” high x 38” deep slide-out drawer  rated at 800 lbs. on left and right side  forward of rear wheels.
  • Drop-down step platforms on left and right rear compartment.
  • Bi-fold robot ramp rated at 1000 lbs
  • Roof ladder storage in recessed roof
  • Roof ladder roller on edge of roof
  • Wheelskirt SCBA bottle storage tubes – total of 10 fore and aft of rear wheels
  • 30-amp AutoEject shorepower w/auto transfer relay
  • FRC Optimum tripod flood lights (2)
  • FRC Optimum flood lights upper left and right side of body
  • Command light tower with FRC Optimum lamps
  • Hannay cord reels with 200-ft 10/4 cable (2)
  • Power distribution boxes on end of cord (2)
  • 85cfm hydraulic powered air compressor
  • Hannay utility air hose reels (2)
  • Whelen UltraFreedom 88” LED lightbar
  • PowerArc LED oscillators in left and right headlight bezel
  • Whelen LED upper and lower zone warning lights
  • Federal Q2B on left front bumper
  • 12vdc power strip outlets with six terminals in cab and body for auxiliary equipment charging
  • Color rearview camera
  • 20kw Harrison hydraulic generator mounted on roof
  • 30-amp AutoEject shorepower w/auto transfer relay
  • FRC Optimum tripod flood lights (2)
  • FRC Optimum flood lights upper left and right side of body
  • Command light tower with FRC Optimum lamps
  • Hannay cord reels with 200-ft 10/4 cable (2)
  • Power distribution boxes on end of cord (2)
  • 85cfm hydraulic powered air compressor
  • Hannay utility air hose reels (2)

Photos

Charlotte Fire Department Charlotte Fire Department Charlotte Fire Department Charlotte Fire Department Charlotte Fire Department Charlotte Fire Department
